Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
157JFIXED IND 10H 65MA 205 OHM CHASS Hammond Manufacturing |
1 |
|
Datasheet
|
157 | Nonstandard | Bulk | Active | - | - | 10 H | ±15% | 65 mA | - | Unshielded | 205Ohm | - | - | - | - | - | - | Chassis Mount | - | 3.250" L x 1.750" W (82.55mm x 44.45mm) | 2.000" (50.80mm) |
|
|
157QFIXED IND 3.5H 150MA 98 OHM CHAS Hammond Manufacturing |
1 |
|
Datasheet
|
157 | Nonstandard | Bulk | Active | - | - | 3.5 H | ±15% | 150 mA | - | Unshielded | 98Ohm | - | - | - | - | - | - | Chassis Mount | - | 3.250" L x 1.750" W (82.55mm x 44.45mm) | 2.000" (50.80mm) |
|
194FFIXED IND 5H 120MA CHAS MNT Hammond Manufacturing |
1 |
|
Datasheet
|
194 | - | Bulk | Active | - | - | 5 H | - | 120 mA | - | - | - | - | - | - | - | - | - | Chassis Mount | - | 2.573" L x 2.188" W (65.35mm x 55.58mm) | 2.625" (66.68mm) |
|
|
157GFIXED IND 30H 40MA 595 OHM CHASS Hammond Manufacturing |
4 |
|
Datasheet
|
157 | Nonstandard | Bulk | Active | - | - | 30 H | ±15% | 40 mA | - | Unshielded | 595Ohm | - | - | - | - | - | - | Chassis Mount | - | 3.250" L x 1.750" W (82.55mm x 44.45mm) | 2.000" (50.80mm) |
|
159QFIXED IND 7H 150MA 100 OHM CHASS Hammond Manufacturing |
0 |
|
Datasheet
|
159 | Nonstandard | Bulk | Active | - | - | 7 H | ±15% | 150 mA | - | Unshielded | 100Ohm | - | - | - | - | - | - | Chassis Mount | - | 4.030" L x 2.250" W (102.36mm x 57.15mm) | 2.630" (66.80mm) |
|
|
159MFIXED IND 15H 100MA 256 OHM CHAS Hammond Manufacturing |
5 |
|
Datasheet
|
159 | Nonstandard | Bulk | Active | - | - | 15 H | ±15% | 100 mA | - | Unshielded | 256Ohm | - | - | - | - | - | - | Chassis Mount | - | 4.030" L x 2.250" W (102.36mm x 57.15mm) | 2.630" (66.80mm) |
|
|
194EFIXED IND 30H 100MA 517.2 OHM Hammond Manufacturing |
1 |
|
Datasheet
|
194 | Nonstandard | Box | Active | - | - | 30 H | ±15% | 100 mA | - | Unshielded | 517.2Ohm | - | - | - | - | - | - | Chassis Mount | - | 4.000" L x 2.085" W (101.60mm x 52.96mm) | 2.620" (66.55mm) |
|
|
194DFIXED IND 5H 150MA 107.2 OHM Hammond Manufacturing |
0 |
|
Datasheet
|
194 | Nonstandard | Box | Active | - | - | 5 H | ±15% | 150 mA | - | Unshielded | 107.2Ohm | - | - | - | - | - | - | Chassis Mount | - | 2.188" L x 2.447" W (55.58mm x 62.15mm) | 2.625" (66.68mm) |
|
|
194CFIXED IND 40H 50MA 420.2 OHM Hammond Manufacturing |
1 |
|
Datasheet
|
194 | Nonstandard | Box | Active | - | - | 40 H | ±15% | 50 mA | - | Unshielded | 420.2Ohm | - | - | - | - | - | - | Chassis Mount | - | 2.500" L x 2.781" W (63.50mm x 70.64mm) | 3.000" (76.20mm) |
|
197AB25FIXED IND 150UH 25A 0.01OHM SMD Hammond Manufacturing |
1 |
|
Datasheet
|
197 | Nonstandard | Box | Active | Powdered Iron Core | Carbonyl Powder | 150 µH | ±15% | 25 A | - | Unshielded | 10mOhm | - | 1.45MHz | - | -40°C ~ 105°C | - | - | Surface Mount | - | 3.400" L x 2.500" W (86.36mm x 63.50mm) | 3.376" (85.75mm) |
