onsemi FDMS7620S
- Part No.:
- FDMS7620S
- Manufacturer:
- onsemi
- Category:
- FET, MOSFET Arrays
- Package:
- 8-PowerWDFN
- Datasheet:
-
FDMS7620S.pdf
- Description:
- MOSFET 2N-CH 30V 10.1A POWER56
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
FDMS7620S Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- onsemi
- Series:
- PowerTrench®
- Package/Case:
- 8-PowerWDFN
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Technology:
- MOSFET (Metal Oxide)
- Configuration:
- 2 N-Channel (Dual)
- FET Feature:
- Logic Level Gate
- Drain to Source Voltage (Vdss):
- 30V
- Current - Continuous Drain (Id) @ 25°C:
- 10.1A, 12.4A
- Rds On (Max) @ Id, Vgs:
- 20mOhm @ 10.1A, 10V
- Vgs(th) (Max) @ Id:
- 3V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs:
- 11nC @ 10V
- Input Capacitance (Ciss) (Max) @ Vds:
- 608pF @ 15V
- Power - Max:
- 1W
- Operating Temperature:
- -55°C ~ 150°C (TJ)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- Power56
- Datasheet:
-
FDMS7620S.pdf
| Image |  |
 |
| Part Number | FDMS7620S | FDMS7620S-F106 |
| Manufacturer | onsemi | onsemi |
| Series | PowerTrench® | PowerTrench® |
| Package/Case | 8-PowerWDFN | 8-PowerWDFN |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Obsolete |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) | 2 N-Channel (Half Bridge) |
| FET Feature | Logic Level Gate | - |
| Drain to Source Voltage (Vdss) | 30V | 30V |
| Current - Continuous Drain (Id) @ 25°C | 10.1A, 12.4A | 10.1A, 12.4A |
| Rds On (Max) @ Id, Vgs | 20mOhm @ 10.1A, 10V | 20mOhm @ 10.1A, 10V |
| Vgs(th) (Max) @ Id | 3V @ 250µA | 3V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 11nC @ 10V | 11nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 608pF @ 15V | 608pF @ 15V |
| Power - Max | 1W | 1W |
| Operating Temperature | -55°C ~ 150°C (TJ) | - |
| Grade | - | - |
| Qualification | - | - |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | Power56 | Power56 |
