Toshiba Semiconductor and Storage XPN7R104NC,L1XHQ
- Part No.:
- XPN7R104NC,L1XHQ
- Manufacturer:
- Toshiba Semiconductor and Storage
- Category:
- FETs, MOSFETs
- Package:
- 8-PowerVDFN
- Datasheet:
-
XPN7R104NC,L1XHQ.pdf
- Description:
- MOSFET N-CH 40V 20A 8TSON
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
XPN7R104NC,L1XHQ Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Toshiba Semiconductor and Storage
- Series:
- U-MOSIII
- Package/Case:
- 8-PowerVDFN
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- FET Type:
- N-Channel
- Technology:
- MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss):
- 40 V
- Current - Continuous Drain (Id) @ 25°C:
- 20A (Ta)
- Drive Voltage (Max Rds On, Min Rds On):
- 4.5V, 10V
- Rds On (Max) @ Id, Vgs:
- 7.1mOhm @ 10A, 10V
- Vgs(th) (Max) @ Id:
- 2.5V @ 200µA
- Gate Charge (Qg) (Max) @ Vgs:
- 21 nC @ 10 V
- Vgs (Max):
- ±20V
- Input Capacitance (Ciss) (Max) @ Vds:
- 1290 pF @ 10 V
- FET Feature:
- -
- Power Dissipation (Max):
- 840mW (Ta), 65W (Tc)
- Operating Temperature:
- 175°C
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 8-TSON Advance-WF (3.1x3.1)
- Datasheet:
-
XPN7R104NC,L1XHQ.pdf
| Image |  |
| Part Number | XPN7R104NC,L1XHQ |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | U-MOSIII |
| Package/Case | 8-PowerVDFN |
| Packaging | Tape & Reel (TR) |
| Product Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 20A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 7.1mOhm @ 10A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 200µA |
| Gate Charge (Qg) (Max) @ Vgs | 21 nC @ 10 V |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 1290 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 840mW (Ta), 65W (Tc) |
| Operating Temperature | 175°C |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-TSON Advance-WF (3.1x3.1) |
