TDK Corporation UHV-11A
- Part No.:
- UHV-11A
- Manufacturer:
- TDK Corporation
- Category:
- Ceramic Capacitors
- Package:
- Datasheet:
-
UHV-11A.pdf
- Description:
- CAP CER 1000PF 50KV Z5T DISK
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
UHV-11A Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- TDK Corporation
- Series:
- UHV
- Packaging:
- Tray
- Product Status:
- Active
- Capacitance:
- 1000 pF
- Tolerance:
- ±10%
- Voltage - Rated:
- 50000V (50kV)
- Temperature Coefficient:
- Z5T
- Operating Temperature:
- -30°C ~ 85°C
- Features:
- High Voltage, Low Dissipation Factor
- Ratings:
- -
- Applications:
- General Purpose
- Failure Rate:
- -
- Mounting Type:
- Requires Holder
- Package / Case:
- Disk, Metal Fitting - Threaded
- Size / Dimension:
- 1.890" Dia x 1.378" L (48.00mm x 35.00mm)
- Height - Seated (Max):
- -
- Thickness (Max):
- -
- Lead Spacing:
- -
- Lead Style:
- -
- Datasheet:
-
UHV-11A.pdf
| Image |  |
 |
 |
 |
 |
| Part Number | UHV-251A | UHV-11A | UHV-9A | UHV-2A | UHV-4A |
| Manufacturer | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation | TDK Corporation |
| Series | UHV | UHV | UHV | UHV | UHV |
| Packaging | Bulk | Tray | Bulk | Bulk | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Capacitance | 100 pF | 1000 pF | 2000 pF | 2500 pF | 940 pF |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% |
| Voltage - Rated | 50000V (50kV) | 50000V (50kV) | 40000V (40kV) | 20000V (20kV) | 30000V (30kV) |
| Temperature Coefficient | Z5T | Z5T | Z5T | Z5T | Z5T |
| Operating Temperature | -30°C ~ 85°C | -30°C ~ 85°C | -30°C ~ 85°C | -30°C ~ 85°C | -30°C ~ 85°C |
| Features | High Voltage, Low Dissipation Factor | High Voltage, Low Dissipation Factor | High Voltage, Low Dissipation Factor | High Voltage, Low Dissipation Factor | High Voltage, Low Dissipation Factor |
| Ratings | - | - | - | - | - |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - | - | - |
| Mounting Type | Requires Holder | Requires Holder | Requires Holder | Requires Holder | Requires Holder |
| Package / Case | Disk, Metal Fitting - Threaded | Disk, Metal Fitting - Threaded | Disk, Metal Fitting - Threaded | Disk, Metal Fitting - Threaded | Disk, Metal Fitting - Threaded |
| Size / Dimension | 0.787" Dia x 1.378" L (20.00mm x 35.00mm) | 1.890" Dia x 1.378" L (48.00mm x 35.00mm) | 2.362" Dia x 1.299" L (60.00mm x 33.00mm) | 1.890" Dia x 0.906" L (48.00mm x 23.00mm) | 1.496" Dia x 1.063" L (38.00mm x 27.00mm) |
| Height - Seated (Max) | - | - | - | - | - |
| Thickness (Max) | - | - | - | - | - |
| Lead Spacing | - | - | - | - | - |
| Lead Style | - | - | - | - | - |
