SMC Diode Solutions SD05
- Part No.:
- SD05
- Manufacturer:
- SMC Diode Solutions
- Category:
- TVS Diodes
- Package:
- SC-76, SOD-323
- Datasheet:
-
SD05.pdf
- Description:
- TVS ARRAY 5V SOD-323
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
SD05 Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- SMC Diode Solutions
- Package/Case:
- SC-76, SOD-323
- Series:
- SDxx
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Type:
- Zener
- Unidirectional Channels:
- 1
- Bidirectional Channels:
- -
- Voltage - Reverse Standoff (Typ):
- 5V (Max)
- Voltage - Breakdown (Min):
- 6V
- Voltage - Clamping (Max) @ Ipp:
- 14.5V
- Current - Peak Pulse (10/1000µs):
- 24A (8/20µs)
- Power - Peak Pulse:
- 350W
- Power Line Protection:
- No
- Applications:
- General Purpose
- Capacitance @ Frequency:
- 350pF @ 1MHz (Max)
- Operating Temperature:
- -55°C ~ 125°C (TJ)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- SOD-323
- Datasheet:
-
SD05.pdf
| Image |  |
 |
|
|
| Part Number | SD05 | SD05C | SD05LC | SD05LCC |
| Manufacturer | SMC Diode Solutions | SMC Diode Solutions | SMC Diode Solutions | SMC Diode Solutions |
| Package/Case | SC-76, SOD-323 | SC-76, SOD-323 | SC-76, SOD-323 | SC-76, SOD-323 |
| Series | SDxx | SDxxC | SDxxLC | SDxxLCC |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Active |
| Type | Zener | Zener | Zener | Zener |
| Unidirectional Channels | 1 | - | 1 | - |
| Bidirectional Channels | - | 1 | - | 1 |
| Voltage - Reverse Standoff (Typ) | 5V (Max) | 5V (Max) | 5V (Max) | 5V (Max) |
| Voltage - Breakdown (Min) | 6V | 6V | 6V | 6V |
| Voltage - Clamping (Max) @ Ipp | 14.5V | 14.5V | 18.3V | 18.3V |
| Current - Peak Pulse (10/1000µs) | 24A (8/20µs) | 24A (8/20µs) | 17A (8/20µs) | 17A (8/20µs) |
| Power - Peak Pulse | 350W | 350W | 350W | 350W |
| Power Line Protection | No | Yes | Yes | Yes |
| Applications | General Purpose | General Purpose | Ethernet, USB | Ethernet, USB |
| Capacitance @ Frequency | 350pF @ 1MHz (Max) | 200pF @ 1MHz (Max) | 5pF @ 1MHz (Max) | 5pF @ 1MHz (Max) |
| Operating Temperature | -55°C ~ 125°C (TJ) | -55°C ~ 125°C (TJ) | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Grade | - | - | - | - |
| Qualification | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | SOD-323 | SOD-323 | SOD-323 | SOD-323 |
