Schneider Electric RSB1A120BD
- Part No.:
- RSB1A120BD
- Manufacturer:
- Schneider Electric
- Category:
- Power Relays, Over 2 Amps
- Package:
- Datasheet:
-
RSB1A120BD.pdf
- Description:
- HARMONY, INTERFACE PLUG-IN RELAY
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
RSB1A120BD Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Schneider Electric
- Series:
- Harmony
- Packaging:
- Box
- Product Status:
- Active
- Mounting Type:
- Socketable
- Coil Voltage:
- 24VDC
- Contact Form:
- SPDT (1 Form C)
- Contact Rating (Current):
- 12 A
- Switching Voltage:
- 300VDC - Max
- Load - Max Switching:
- 3600VA
- Coil Current:
- 16.7 mA
- Coil Type:
- Non Latching
- Features:
- -
- Termination Style:
- Plug In
- Seal Rating:
- -
- Coil Insulation:
- -
- Must Operate Voltage:
- -
- Must Release Voltage:
- 2.4 VDC
- Operate Time:
- 20 ms
- Release Time:
- 20 ms
- Operating Temperature:
- -40°C ~ 85°C
- Contact Material:
- Silver Nickel (AgNi)
- Relay Type:
- General Purpose
- Grade:
- -
- Qualification:
- -
- Datasheet:
-
RSB1A120BD.pdf
| Image |  |
 |
 |
| Part Number | RSB1A120BD | RSB1A120BDS | RSB1A120BDPV |
| Manufacturer | Schneider Electric | Schneider Electric | Schneider Electric |
| Series | Harmony | Harmony | Harmony |
| Packaging | Box | Box | Bulk |
| Product Status | Active | Obsolete | Active |
| Mounting Type | Socketable | DIN Rail | DIN Rail |
| Coil Voltage | 24VDC | 24VDC | 24VDC |
| Contact Form | SPDT (1 Form C) | SPDT (1 Form C) | SPDT (1 Form C) |
| Contact Rating (Current) | 12 A | 12 A | 12 A |
| Switching Voltage | 300VDC - Max | 400VAC, 300VDC - Max | 250VAC, 28VDC - Max |
| Load - Max Switching | 3600VA | 4800VA, 3600W | 3000VA, 336W |
| Coil Current | 16.7 mA | 16.7 mA | 16.7 mA |
| Coil Type | Non Latching | Non Latching | Non Latching |
| Features | - | - | Lighted Indicator |
| Termination Style | Plug In | Screw Terminal | Screw Terminal |
| Seal Rating | - | - | - |
| Coil Insulation | - | - | - |
| Must Operate Voltage | - | 19.2 VDC | 19.2 VDC |
| Must Release Voltage | 2.4 VDC | 2.4 VDC | 2.4 VDC |
| Operate Time | 20 ms | 4 ms | 20 ms |
| Release Time | 20 ms | 9 ms | 20 ms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 70°C | -40°C ~ 85°C |
| Contact Material | Silver Nickel (AgNi) | Silver Nickel (AgNi) | Silver Nickel (AgNi) |
| Relay Type | General Purpose | General Purpose | General Purpose |
| Grade | - | - | - |
| Qualification | - | - | - |
