Panasonic Electronic Components ECE-A1HKA4R7B
- Part No.:
- ECE-A1HKA4R7B
- Manufacturer:
- Panasonic Electronic Components
- Category:
- Aluminum Electrolytic Capacitors
- Package:
- Datasheet:
-
ECE-A1HKA4R7B.pdf
- Description:
- CAP ALUM 4.7UF 20% 50V RADIAL TH
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ECE-A1HKA4R7B Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Panasonic Electronic Components
- Package/Case:
- Series:
- KA
- Packaging:
- Cut Tape (CT)
- Product Status:
- Active
- Capacitance:
- 4.7 µF
- Tolerance:
- ±20%
- Voltage - Rated:
- 50 V
- ESR (Equivalent Series Resistance):
- -
- Lifetime @ Temp.:
- 1000 Hrs @ 85°C
- Operating Temperature:
- -40°C ~ 85°C
- Polarization:
- Polar
- Ratings:
- -
- Applications:
- General Purpose
- Ripple Current @ Low Frequency:
- 23 mA @ 120 Hz
- Ripple Current @ High Frequency:
- 39.1 mA @ 10 kHz
- Impedance:
- -
- Lead Spacing:
- 0.197" (5.00mm)
- Size / Dimension:
- 0.157" Dia (4.00mm)
- Height - Seated (Max):
- 0.315" (8.00mm)
- Surface Mount Land Size:
- -
- Mounting Type:
- Through Hole
- Datasheet:
-
ECE-A1HKA4R7B.pdf
| Image |  |
|
 |
 |
|
| Part Number | ECE-A1HKA4R7B | ECE-A1HKA3R3I | ECE-A1EN471UB | ECE-A0JN332U | ECE-A1AN332U |
| Manufacturer | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components | Panasonic Electronic Components |
| Package/Case | |||||
| Series | KA | KA | SU | SU | SU |
| Packaging | Cut Tape (CT) | Cut Tape (CT) | Cut Tape (CT) | Bulk | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| Capacitance | 4.7 µF | 3.3 µF | 470 µF | 3300 µF | 3300 µF |
| Tolerance | ±20% | ±20% | ±20% | ±20% | ±20% |
| Voltage - Rated | 50 V | 50 V | 25 V | 6.3 V | 10 V |
| ESR (Equivalent Series Resistance) | - | - | - | - | - |
| Lifetime @ Temp. | 1000 Hrs @ 85°C | 1000 Hrs @ 85°C | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Polarization | Polar | Polar | Bi-Polar | Bi-Polar | Bi-Polar |
| Ratings | - | - | - | - | - |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Ripple Current @ Low Frequency | 23 mA @ 120 Hz | 18 mA @ 120 Hz | 430 mA @ 120 Hz | 760 mA @ 120 Hz | 1.09 A @ 120 Hz |
| Ripple Current @ High Frequency | 39.1 mA @ 10 kHz | 30.6 mA @ 10 kHz | 731 mA @ 10 kHz | 1.292 A @ 10 kHz | 1.853 A @ 10 kHz |
| Impedance | - | - | - | - | - |
| Lead Spacing | 0.197" (5.00mm) | 0.098" (2.50mm) | 0.197" (5.00mm) | 0.295" (7.50mm) | 0.295" (7.50mm) |
| Size / Dimension | 0.157" Dia (4.00mm) | 0.157" Dia (4.00mm) | 0.492" Dia (12.50mm) | 0.630" Dia (16.00mm) | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 0.315" (8.00mm) | 0.315" (8.00mm) | 0.866" (22.00mm) | 0.984" (25.00mm) | 1.240" (31.50mm) |
| Surface Mount Land Size | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
