Littelfuse Inc. SP12-01WTG-C-HV
- Part No.:
- SP12-01WTG-C-HV
- Manufacturer:
- Littelfuse Inc.
- Category:
- TVS Diodes
- Package:
- 2-XFDFN, FCDFN
- Datasheet:
-
SP12-01WTG-C-HV.pdf
- Description:
- TVS DIODE 12VWM 19VC 2FLIPCHIP
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
SP12-01WTG-C-HV Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Littelfuse Inc.
- Package/Case:
- 2-XFDFN, FCDFN
- Series:
- SPXX, SPA®
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Type:
- Zener
- Unidirectional Channels:
- -
- Bidirectional Channels:
- 1
- Voltage - Reverse Standoff (Typ):
- 12V (Max)
- Voltage - Breakdown (Min):
- 13.3V
- Voltage - Clamping (Max) @ Ipp:
- 19V
- Current - Peak Pulse (10/1000µs):
- 8A (8/20µs)
- Power - Peak Pulse:
- 100W
- Power Line Protection:
- No
- Applications:
- General Purpose
- Capacitance @ Frequency:
- 26pF @ 1MHz
- Operating Temperature:
- -40°C ~ 125°C (TJ)
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 2-FlipChip
- Datasheet:
-
SP12-01WTG-C-HV.pdf
| Image |  |
 |
 |
|
 |
| Part Number | SP12-01WTG-C-HV | SP1233-01ETG | SP1250-01ETG | SP1212-01ETG | SP1224-01UTG |
| Manufacturer | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. | Littelfuse Inc. |
| Package/Case | 2-XFDFN, FCDFN | SOD-882 | SOD-882 | SOD-882 | 6-UFDFN Exposed Pad |
| Series | SPXX, SPA® | SP1220, SPA® | SP1250, SPA® | SP1212, SPA® | SP1220, SPA® |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Obsolete | Active |
| Type | Zener | Zener | Zener | Zener | Zener |
| Unidirectional Channels | - | - | 1 | 1 | 1 |
| Bidirectional Channels | 1 | 1 | - | - | - |
| Voltage - Reverse Standoff (Typ) | 12V (Max) | 3.3V (Max) | 5V (Max) | 5V (Max) | 22V (Max) |
| Voltage - Breakdown (Min) | 13.3V | 4.2V (Typ) | 5.5V | 7V (Typ) | 24V |
| Voltage - Clamping (Max) @ Ipp | 19V | 8.5V (Typ) | 10V | 9.7V (Typ) | 37V |
| Current - Peak Pulse (10/1000µs) | 8A (8/20µs) | 20A (8/20µs) | 50A (8/20µs) | 12A (8/20µs) | 100A (8/20µs) |
| Power - Peak Pulse | 100W | 180W | - | 250W | 3700W (3.7kW) |
| Power Line Protection | No | No | No | No | No |
| Applications | General Purpose | - | - | - | General Purpose |
| Capacitance @ Frequency | 26pF @ 1MHz | 35pF @ 1MHz | 118pF @ 1MHz | 290pF @ 1MHz | 770pF @ 1MHz |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 125°C | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Grade | - | Automotive | Automotive | Automotive | - |
| Qualification | - | AEC-Q101 | - | AEC-Q101 | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 2-FlipChip | SOD-882 | SOD-882 | SOD-882 | 6-µDFN (1.8x2) |
