Fairchild Semiconductor KA1H0165RTU
- Part No.:
- KA1H0165RTU
- Manufacturer:
- Fairchild Semiconductor
- Category:
- AC DC Converters, Offline Switches
- Package:
- TO-220-4 Full Pack
- Datasheet:
-
KA1H0165RTU.pdf
- Description:
- IC OFFLINE SW MULT TOP TO220F
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
KA1H0165RTU Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Fairchild Semiconductor
- Series:
- FPS™
- Package/Case:
- TO-220-4 Full Pack
- Packaging:
- Bulk
- Product Status:
- Active
- Output Isolation:
- Non-Isolated
- Internal Switch(s):
- Yes
- Voltage - Breakdown:
- 650V
- Topology:
- Flyback, Forward
- Voltage - Start Up:
- 15 V
- Voltage - Supply (Vcc/Vdd):
- 10V ~ 30V
- Duty Cycle:
- 67%
- Frequency - Switching:
- 100kHz
- Power (Watts):
- -
- Fault Protection:
- Current Limiting, Over Load, Over Temperature, Over Voltage
- Control Features:
- Soft Start
- Operating Temperature:
- -25°C ~ 85°C (TA)
- Grade:
- -
- Qualification:
- -
- Supplier Device Package:
- TO-220F-4
- Mounting Type:
- Through Hole
- Datasheet:
-
KA1H0165RTU.pdf
| Image |  |
| Part Number | KA1H0165RTU |
| Manufacturer | Fairchild Semiconductor |
| Series | FPS™ |
| Package/Case | TO-220-4 Full Pack |
| Packaging | Bulk |
| Product Status | Active |
| Output Isolation | Non-Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 650V |
| Topology | Flyback, Forward |
| Voltage - Start Up | 15 V |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 30V |
| Duty Cycle | 67% |
| Frequency - Switching | 100kHz |
| Power (Watts) | - |
| Fault Protection | Current Limiting, Over Load, Over Temperature, Over Voltage |
| Control Features | Soft Start |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Grade | - |
| Qualification | - |
| Supplier Device Package | TO-220F-4 |
| Mounting Type | Through Hole |
