Cornell Dubilier Knowles WBR150-75A
- Part No.:
- WBR150-75A
- Manufacturer:
- Cornell Dubilier Knowles
- Category:
- Aluminum Electrolytic Capacitors
- Package:
- Datasheet:
-
WBR150-75A.pdf
- Description:
- CAP ALUM 150UF 75V AXIAL TH
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
WBR150-75A Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Cornell Dubilier Knowles
- Package/Case:
- Series:
- WBR
- Packaging:
- Bulk
- Product Status:
- Obsolete
- Capacitance:
- 150 µF
- Tolerance:
- -10%, +100%
- Voltage - Rated:
- 75 V
- ESR (Equivalent Series Resistance):
- 2.5Ohm @ 120Hz
- Lifetime @ Temp.:
- 2000 Hrs @ 85°C
- Operating Temperature:
- -40°C ~ 85°C
- Polarization:
- Polar
- Ratings:
- -
- Applications:
- General Purpose
- Ripple Current @ Low Frequency:
- 180 mA @ 120 Hz
- Ripple Current @ High Frequency:
- 216 mA @ 100 kHz
- Impedance:
- -
- Lead Spacing:
- -
- Size / Dimension:
- 0.470" Dia x 1.320" L (11.94mm x 33.53mm)
- Height - Seated (Max):
- -
- Surface Mount Land Size:
- -
- Mounting Type:
- Through Hole
- Datasheet:
-
WBR150-75A.pdf
| Image |  |
 |
|
 |
 |
| Part Number | WBR150-150A | WBR150-35A | WBR150-50A | WBR150-75A | WBR1500-50A |
| Manufacturer | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles | Cornell Dubilier Knowles |
| Package/Case | |||||
| Series | WBR | WBR | WBR | WBR | WBR |
| Packaging | Bulk | Bulk | Bulk | Bulk | Bulk |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Capacitance | 150 µF | 150 µF | 150 µF | 150 µF | 1500 µF |
| Tolerance | -10%, +100% | -10%, +150% | -10%, +150% | -10%, +100% | -10%, +150% |
| Voltage - Rated | 150 V | 35 V | 50 V | 75 V | 50 V |
| ESR (Equivalent Series Resistance) | 2.05Ohm @ 120Hz | 2.95Ohm @ 120Hz | 2.5Ohm @ 120Hz | 2.5Ohm @ 120Hz | 250mOhm @ 120Hz |
| Lifetime @ Temp. | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Polarization | Polar | Polar | Polar | Polar | Polar |
| Ratings | - | - | - | - | - |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose | General Purpose |
| Ripple Current @ Low Frequency | 230 mA @ 120 Hz | 114 mA @ 120 Hz | 160 mA @ 120 Hz | 180 mA @ 120 Hz | 740 mA @ 120 Hz |
| Ripple Current @ High Frequency | 276 mA @ 100 kHz | 131.1 mA @ 100 kHz | 184 mA @ 100 kHz | 216 mA @ 100 kHz | 851 mA @ 100 kHz |
| Impedance | - | - | - | - | - |
| Lead Spacing | - | - | - | - | - |
| Size / Dimension | 0.740" Dia x 1.690" L (18.80mm x 42.93mm) | 0.400" Dia x 1.000" L (10.16mm x 25.40mm) | 0.400" Dia x 1.000" L (10.16mm x 25.40mm) | 0.470" Dia x 1.320" L (11.94mm x 33.53mm) | 0.650" Dia x 1.830" L (16.51mm x 46.48mm) |
| Height - Seated (Max) | - | - | - | - | - |
| Surface Mount Land Size | - | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
