Broadcom Limited ACNT-H343-000E
- Part No.:
- ACNT-H343-000E
- Manufacturer:
- Broadcom Limited
- Category:
- Isolators - Gate Drivers
- Package:
- 8-SOIC (0.535", 13.60mm Width)
- Datasheet:
-
ACNT-H343-000E.pdf
- Description:
- OPTOISO 7.5KV 1CH GATE DVR 8SO
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ACNT-H343-000E Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Broadcom Limited
- Series:
- -
- Package/Case:
- 8-SOIC (0.535", 13.60mm Width)
- Packaging:
- Tube
- Product Status:
- Active
- Technology:
- Optical Coupling
- Number of Channels:
- 1
- Voltage - Isolation:
- 7500Vrms
- Common Mode Transient Immunity (Min):
- 100kV/µs
- Propagation Delay tpLH / tpHL (Max):
- 150ns, 150ns
- Pulse Width Distortion (Max):
- 80ns
- Rise / Fall Time (Typ):
- 26ns, 7.5ns
- Current - Output High, Low:
- 4A, 4A
- Current - Peak Output:
- 5A, 5A
- Voltage - Forward (Vf) (Typ):
- 1.5V
- Current - DC Forward (If) (Max):
- 25 mA
- Voltage - Output Supply:
- 15V ~ 30V
- Grade:
- -
- Qualification:
- -
- Operating Temperature:
- -40°C ~ 110°C
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 8-SO Stretched
- Approval Agency:
- CSA, IEC/EN/DIN, UR
- Datasheet:
-
ACNT-H343-000E.pdf
| Image |  |
 |
|
|
| Part Number | ACNT-H343-000E | ACNT-H313-000E | ACNT-H313-500E | ACNT-H343-500E |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| Series | - | - | - | - |
| Package/Case | 8-SOIC (0.535", 13.60mm Width) | 8-SOIC (0.535", 13.60mm Width) | 8-SOIC (0.535", 13.60mm Width) | 8-SOIC (0.535", 13.60mm Width) |
| Packaging | Tube | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
| Product Status | Active | Active | Active | Active |
| Technology | Optical Coupling | Optical Coupling | Optical Coupling | Optical Coupling |
| Number of Channels | 1 | 1 | 1 | 1 |
| Voltage - Isolation | 7500Vrms | 7500Vrms | 7500Vrms | 7500Vrms |
| Common Mode Transient Immunity (Min) | 100kV/µs | 40kV/µs | 40kV/µs | 100kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 150ns, 150ns | 500ns, 500ns | 500ns, 500ns | 150ns, 150ns |
| Pulse Width Distortion (Max) | 80ns | 300ns | 300ns | 80ns |
| Rise / Fall Time (Typ) | 26ns, 7.5ns | 100ns, 100ns | 100ns, 100ns | 26ns, 7.5ns |
| Current - Output High, Low | 4A, 4A | 2A, 2A | 2A, 2A | 4A, 4A |
| Current - Peak Output | 5A, 5A | 2.5A | 2.5A | 5A, 5A |
| Voltage - Forward (Vf) (Typ) | 1.5V | 1.45V | 1.45V | 1.5V |
| Current - DC Forward (If) (Max) | 25 mA | 25 mA | 25 mA | 25 mA |
| Voltage - Output Supply | 15V ~ 30V | 15V ~ 30V | 15V ~ 30V | 15V ~ 30V |
| Grade | - | - | - | - |
| Qualification | - | - | - | - |
| Operating Temperature | -40°C ~ 110°C | -40°C ~ 105°C | -40°C ~ 105°C | -40°C ~ 110°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 8-SO Stretched | 8-SO Stretched | 8-SO Stretched | 8-SO Stretched |
| Approval Agency | CSA, IEC/EN/DIN, UR | CSA, IEC/EN/DIN, UR | CSA, IEC/EN/DIN, UR | CSA, IEC/EN/DIN, UR |
