Amphenol PCTEL 3917D
- Part No.:
- 3917D
- Manufacturer:
- Amphenol PCTEL
- Category:
- RF Antennas
- Package:
- Datasheet:
-
3917D.pdf
- Description:
- RF ANT 1.575GHZ MOD SMA MALE MAG
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
3917D Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Amphenol PCTEL
- Series:
- -
- Packaging:
- Bulk
- Product Status:
- Active
- RF Family/Standard:
- Navigation
- Frequency Group:
- UHF (1GHz ~ 2GHz)
- Frequency (Center/Band):
- 1.575GHz
- Frequency Range:
- 1.565GHz ~ 1.585GHz
- Antenna Type:
- Module
- Number of Bands:
- 1
- VSWR:
- -
- Return Loss:
- -
- Gain:
- 3dBic, -2dBic
- Power - Max:
- -
- Features:
- Cable - 3m, LNA, Filter
- Termination:
- SMA Male
- Ingress Protection:
- IP67
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Magnetic
- Height (Max):
- 0.535" (13.60mm)
- Applications:
- GNSS, GPS
- Datasheet:
-
3917D.pdf
| Image |  |
 |
 |
|
|
| Part Number | 3917D | 3917D-5M-SMA | 3917D-75CM-SMA | 3917D-3M-SMC | 3917D-5M-SMC |
| Manufacturer | Amphenol PCTEL | Amphenol PCTEL | Amphenol PCTEL | Amphenol PCTEL | Amphenol PCTEL |
| Series | - | - | - | - | - |
| Packaging | Bulk | Box | Bulk | Bulk | Bulk |
| Product Status | Active | Active | Active | Active | Active |
| RF Family/Standard | Navigation | Navigation | Navigation | Navigation | Navigation |
| Frequency Group | UHF (1GHz ~ 2GHz) | UHF (1GHz ~ 2GHz) | UHF (1GHz ~ 2GHz) | UHF (1GHz ~ 2GHz) | UHF (1GHz ~ 2GHz) |
| Frequency (Center/Band) | 1.575GHz | 1.575GHz | 1.575GHz | 1.575GHz | 1.575GHz |
| Frequency Range | 1.565GHz ~ 1.585GHz | 1.565GHz ~ 1.585GHz | 1.565GHz ~ 1.585GHz | 1.565GHz ~ 1.585GHz | 1.565GHz ~ 1.585GHz |
| Antenna Type | Module | Module | Module | Module | Module |
| Number of Bands | 1 | 1 | 1 | 1 | 1 |
| VSWR | - | - | - | - | - |
| Return Loss | - | - | - | - | - |
| Gain | 3dBic, -2dBic | -2dBic, 3dBic | 3dBic | 3dBic | 3dBic |
| Power - Max | - | - | - | - | - |
| Features | Cable - 3m, LNA, Filter | Cable - 5m, LNA, Filter | Cable - 750mm, LNA, Filter | Cable - 3m, LNA, Filter | Cable - 248.92mm, LNA, Filter |
| Termination | SMA Male | SMA Male | SMA Male | SMA Male | SMA Male |
| Ingress Protection | IP67 | IP67 | IP67 | IP67 | IP67 |
| Grade | - | - | - | - | - |
| Qualification | - | - | - | - | - |
| Mounting Type | Magnetic | Magnetic | Magnetic, Screw | Magnetic, Screw | Connector Mount |
| Height (Max) | 0.535" (13.60mm) | 0.535" (13.60mm) | 0.535" (13.60mm) | 0.535" (13.60mm) | 0.540" (13.72mm) |
| Applications | GNSS, GPS | GNSS, GPS | GPS | GPS | GPS |
