CPLDs (Complex Programmable Logic Devices)(4119)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Programmable Type | Delay Time tpd(1) Max | Voltage Supply - Internal | Number of Logic Elements/Blocks | Number of Macrocells | Number of Gates | Number of I/O | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XCR3512XL-10FG324IIC CPLD 512MC 9NS 324FBGA |
0 |
|
Datasheet
|
CoolRunner XPLA3 | 324-BBGA | Bulk | Obsolete | Not Verified | In System Programmable (min 1K program/erase cycles) | 9 ns | 2.7V ~ 3.6V | 32 | 512 | 12000 | 260 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 324-FBGA (23x23) |
|
LC4512V-5FT256CIC CPLD 512MC 5NS 256FTBGA |
1 |
|
Datasheet
|
ispMACH® 4000V | 256-LBGA | Tray | Obsolete | Not Verified | In System Programmable | 5 ns | 3V ~ 3.6V | 32 | 512 | - | 208 | 0°C ~ 90°C (TJ) | - | - | Surface Mount | 256-FTBGA (17x17) |
.jpg)
|
XC9536-15PC44CIC CPLD 36MC 15NS 44PLCC |
0 |
|
Datasheet
|
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.75V ~ 5.25V | 2 | 36 | 800 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
XC9536-15VQ44CIC CPLD 36MC 15NS 44VQFP |
0 |
|
Datasheet
|
XC9500 | 44-TQFP | Tray | Obsolete | Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.75V ~ 5.25V | 2 | 36 | 800 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-VQFP (10x10) |
|
|
XC9536-7PC44CIC CPLD 36MC 7.5NS 44PLCC |
0 |
|
Datasheet
|
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | 2 | 36 | 800 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
|
XC9572-15PC44CIC CPLD 72MC 15NS 44PLCC |
0 |
|
Datasheet
|
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.75V ~ 5.25V | 4 | 72 | 1600 | 34 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
XC9572-7PQ100CIC CPLD 72MC 7.5NS 100QFP |
0 |
|
Datasheet
|
XC9500 | 100-BQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | 4 | 72 | 1600 | 72 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-PQFP (20x14) |
|
|
XC9572-10PQ100CIC CPLD 72MC 10NS 100QFP |
0 |
|
Datasheet
|
XC9500 | 100-BQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | 4 | 72 | 1600 | 72 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-PQFP (20x14) |
|
XC95108-15PC84CIC CPLD 108MC 15NS 84PLCC |
0 |
|
Datasheet
|
XC9500 | 84-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.75V ~ 5.25V | 6 | 108 | 2400 | 69 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 84-PLCC (29.31x29.31) |
|
|
XC95108-7PC84CIC CPLD 108MC 7.5NS 84PLCC |
0 |
|
Datasheet
|
XC9500 | 84-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | 6 | 108 | 2400 | 69 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 84-PLCC (29.31x29.31) |
|
XC95108-15TQ100CIC CPLD 108MC 15NS 100TQFP |
0 |
|
Datasheet
|
XC9500 | 100-LQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.75V ~ 5.25V | 6 | 108 | 2400 | 81 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
|
|
XC95108-10PQ100CIC CPLD 108MC 10NS 100QFP |
0 |
|
Datasheet
|
XC9500 | 100-BQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | 6 | 108 | 2400 | 81 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-PQFP (20x14) |
|
|
XC95108-7PQ100CIC CPLD 108MC 7.5NS 100QFP |
0 |
|
Datasheet
|
XC9500 | 100-BQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 7.5 ns | 4.75V ~ 5.25V | 6 | 108 | 2400 | 81 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 100-PQFP (20x14) |
|
|
XC9572-15PC44IIC CPLD 72MC 15NS 44PLCC |
0 |
|
Datasheet
|
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 4 | 72 | 1600 | 34 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
|
XC95108-15TQ100IIC CPLD 108MC 15NS 100TQFP |
0 |
|
Datasheet
|
XC9500 | 100-LQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 6 | 108 | 2400 | 81 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 100-TQFP (14x14) |
|
|
XC9536-15PC44IIC CPLD 36MC 15NS 44PLCC |
0 |
|
Datasheet
|
XC9500 | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 4.5V ~ 5.5V | 2 | 36 | 800 | 34 | -40°C ~ 85°C (TA) | - | - | Surface Mount | 44-PLCC (16.59x16.59) |
|
ATF1500ABV-15ACIC CPLD 32MC 15NS 44TQFP |
0 |
|
Datasheet
|
ATF15xx | 44-TQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 3V ~ 5.25V | - | 32 | - | 32 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-TQFP (10x10) |
|
ATF1500ABV-15JCIC CPLD 32MC 15NS 44PLCC |
0 |
|
Datasheet
|
ATF15xx | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 3V ~ 5.25V | - | 32 | - | 32 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.6x16.6) |
|
|
ATF1502ASV-15JC44IC CPLD 32MC 15NS 44PLCC |
0 |
|
Datasheet
|
ATF15xx | 44-LCC (J-Lead) | Tube | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 15 ns | 3V ~ 3.6V | - | 32 | - | 32 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-PLCC (16.6x16.6) |
|
ATF1504AS-10AC44IC CPLD 64MC 10NS 44TQFP |
0 |
|
Datasheet
|
ATF15xx | 44-TQFP | Tray | Obsolete | Not Verified | In System Programmable (min 10K program/erase cycles) | 10 ns | 4.75V ~ 5.25V | - | 64 | - | 32 | 0°C ~ 70°C (TA) | - | - | Surface Mount | 44-TQFP (10x10) |
