Triad Magnetics FP12-3800
- Part No.:
- FP12-3800
- Manufacturer:
- Triad Magnetics
- Category:
- Power Transformers
- Package:
- Datasheet:
-
FP12-3800.pdf
- Description:
- PWR XFMR LAMINATED 48VA TH
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
FP12-3800 Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Triad Magnetics
- Series:
- Flat Pack™
- Packaging:
- Box
- Product Status:
- Active
- Type:
- Laminated Core
- Voltage - Primary:
- 115V, 230V
- Voltage - Secondary (Full Load):
- Parallel 6.3V, Series 12.6V
- Current - Output (Max):
- Parallel 7.6A, Series 3.8A
- Primary Winding(s):
- Dual
- Secondary Winding(s):
- Dual
- Center Tap:
- No
- Power - Max:
- 48VA
- Mounting Type:
- Through Hole
- Termination Style:
- PC Pin
- Size / Dimension:
- 79.25mm L x 63.50mm W
- Height - Seated (Max):
- 34.93mm
- Voltage - Isolation:
- 2000Vrms
- Weight:
- 1.4 lbs (635 g)
- Datasheet:
-
FP12-3800.pdf
| Image |  |
 |
 |
 |
 |
| Part Number | FP12-475 | FP12-950 | FP12-200-B | FP120-20 | FP12-200 |
| Manufacturer | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics | Triad Magnetics |
| Series | Flat Pack™ | Flat Pack™ | Flat Pack™ | Flat Pack™ | Flat Pack™ |
| Packaging | Box | Box | Bulk | Box | Box |
| Product Status | Active | Active | Active | Active | Active |
| Type | Laminated Core | Laminated Core | Laminated Core | Laminated Core | Laminated Core |
| Voltage - Primary | 115V, 230V | 115V, 230V | 115V, 230V | 115V, 230V | 115V, 230V |
| Voltage - Secondary (Full Load) | Parallel 6.3V, Series 12.6V | Parallel 6.3V, Series 12.6V | Parallel 6.3V, Series 12.6V | Parallel 60V, Series 120V | Parallel 6.3V, Series 12.6V |
| Current - Output (Max) | Parallel 950mA, Series 475mA | Parallel 1.9A, Series 950mA | Parallel 400mA, Series 200mA | Parallel 40mA, Series 20mA | Parallel 400mA, Series 200mA |
| Primary Winding(s) | Dual | Dual | Dual | Dual | Dual |
| Secondary Winding(s) | Dual | Dual | Dual | Dual | Dual |
| Center Tap | No | No | No | No | No |
| Power - Max | 6VA | 12VA | 2.5VA | 2.5VA | 2.5VA |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Termination Style | PC Pin | PC Pin | PC Pin | PC Pin | PC Pin |
| Size / Dimension | 47.63mm L x 39.67mm W | 63.50mm L x 50.80mm W | 47.63mm L x 39.67mm W | 47.63mm L x 39.67mm W | 47.63mm L x 39.67mm W |
| Height - Seated (Max) | 22.22mm | 26.97mm | 16.51mm | 16.51mm | 16.51mm |
| Voltage - Isolation | 2000Vrms | 2000Vrms | 2000Vrms | 2000Vrms | 2000Vrms |
| Weight | 0.438 lb (198.67 g) | 0.688 lb (312.07 g) | 0.313 lb (141.97 g) | 0.313 lb (141.97 g) | 0.313 lb (141.97 g) |
