Broadcom Limited ACFJ-332BT-500E
- Part No.:
- ACFJ-332BT-500E
- Manufacturer:
- Broadcom Limited
- Category:
- Isolators - Gate Drivers
- Package:
- 24-SOIC (0.295", 7.50mm Width), 20 Leads
- Description:
- AUTOMOTIVE OPTOCOUPLER, T/R+LF
- Quantity:
Unit Price:$0
Ext Price:$0
- Payment:
- Shipping:
ACFJ-332BT-500E Information
- Specifications
- Product Details
- Comparison
- Tags
- Product attributes
- Attribute value
- Manufacturer:
- Broadcom Limited
- Series:
- -
- Package/Case:
- 24-SOIC (0.295", 7.50mm Width), 20 Leads
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Technology:
- Optical Coupling
- Number of Channels:
- 2
- Voltage - Isolation:
- 5000Vrms
- Common Mode Transient Immunity (Min):
- 150kV/µs
- Propagation Delay tpLH / tpHL (Max):
- 65ns, 65ns
- Pulse Width Distortion (Max):
- 22ns
- Rise / Fall Time (Typ):
- 10ns, 10ns
- Current - Output High, Low:
- 2.5A, 2.4A
- Current - Peak Output:
- 4A
- Voltage - Forward (Vf) (Typ):
- -
- Current - DC Forward (If) (Max):
- -
- Voltage - Output Supply:
- 10V ~ 25V
- Grade:
- Automotive
- Qualification:
- AEC-Q100
- Operating Temperature:
- -40°C ~ 125°C
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- 24-SO
- Approval Agency:
- cUL, UL
| Image |  |
 |
|
|
|
| Part Number | ACFJ-3530T-000E | ACFJ-3262-000E | ACFJ-3262T-000E | ACFJ-3530T-500E | ACFJ-332B-000E |
| Manufacturer | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited | Broadcom Limited |
| Series | - | - | - | - | - |
| Package/Case | 24-SOIC (0.295", 7.50mm Width) | 24-SOIC (0.295", 7.50mm Width), 18 Leads | 24-SOIC (0.295", 7.50mm Width), 18 Leads | 24-SOIC (0.295", 7.50mm Width) | 24-SOIC (0.295", 7.50mm Width), 20 Leads |
| Packaging | Tube | Bulk | Tube | Tape & Reel (TR) | Tube |
| Product Status | Active | Active | Active | Active | Active |
| Technology | Optical Coupling | Capacitive Coupling | Capacitive Coupling | Optical Coupling | Optical Coupling |
| Number of Channels | 1 | 2 | 2 | 1 | 2 |
| Voltage - Isolation | 5000Vrms | 5000Vrms | 5000Vrms | 5000Vrms | 5000Vrms |
| Common Mode Transient Immunity (Min) | 50kV/µs | 100kV/µs | 100kV/µs | 50kV/µs | 150kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 200ns, 200ns | 95ns, 95ns | 95ns, 95ns | 200ns, 200ns | 65ns, 65ns |
| Pulse Width Distortion (Max) | 100ns | 20ns | 20ns | 100ns | 22ns |
| Rise / Fall Time (Typ) | 15ns, 15ns | 7ns, 7ns | 7ns, 7ns | 15ns, 15ns | 10ns, 10ns |
| Current - Output High, Low | 1.5A, 1.5A | 6A, 6A | 6A, 6A | 1.5A, 1.5A | 2.5A, 2.4A |
| Current - Peak Output | 2.5A | 10A | 10A | 2.5A | 4A |
| Voltage - Forward (Vf) (Typ) | 1.55V | 1.55V | 1.55V | 1.55V | - |
| Current - DC Forward (If) (Max) | - | 20 mA | 20 mA | 20 mA | - |
| Voltage - Output Supply | 15.2V ~ 16.8V | 10V ~ 25V | 10V ~ 25V | 15.2V ~ 16.8V | 10V ~ 25V |
| Grade | Automotive | - | Automotive | Automotive | - |
| Qualification | AEC-Q100 | - | AEC-Q100 | AEC-Q100 | - |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 24-SOIC | 24-SO | 24-SO | 24-SOIC | 24-SO |
| Approval Agency | CSA, UL, VDE | CSA, IEC/EN, UL | CSA, IEC/EN, UL | CSA, UL, VDE | cUR, UR |
