Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTHFW2918F-330MSMD SHLDED POWER INDUCTOR Central Technologies |
14 |
|
Datasheet
|
CTHFW2918F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 33 µH | ±20% | 28 A | 8.7A | Shielded | 2.86mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.701" (17.80mm) |
|
CTHFW2915F-330MSMD SHLDED POWER INDUCTOR Central Technologies |
14 |
|
Datasheet
|
CTHFW2915F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 33 µH | ±20% | 30 A | 2.6A | Shielded | 1.76mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.606" (15.40mm) |
|
|
CTHFW2915F-4R7MSMD SHLDED POWER INDUCTOR Central Technologies |
14 |
|
Datasheet
|
CTHFW2915F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 4.7 µH | ±20% | 30 A | 36.9A | Shielded | 1.76mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.606" (15.40mm) |
|
|
CTHFW2918F-220MSMD SHLDED POWER INDUCTOR Central Technologies |
13 |
|
Datasheet
|
CTHFW2918F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 22 µH | ±20% | 28 A | 14A | Shielded | 2.86mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.701" (17.80mm) |
|
|
CTHFW2915F-100MSMD SHLDED POWER INDUCTOR Central Technologies |
12 |
|
Datasheet
|
CTHFW2915F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 10 µH | ±20% | 30 A | 16.2A | Shielded | 1.76mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.606" (15.40mm) |
|
|
CTHFW2915F-220MSMD SHLDED POWER INDUCTOR Central Technologies |
11 |
|
Datasheet
|
CTHFW2915F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 22 µH | ±20% | 30 A | 9A | Shielded | 1.76mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.606" (15.40mm) |
|
|
CTHFW2915F-1R5MSMD SHLDED POWER INDUCTOR Central Technologies |
10 |
|
Datasheet
|
CTHFW2915F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 1.5 µH | ±20% | 30 A | 100A | Shielded | 1.76mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.606" (15.40mm) |
|
|
CTHFW2915F-150MSMD SHLDED POWER INDUCTOR Central Technologies |
5 |
|
Datasheet
|
CTHFW2915F | 2-SMD, Gull Wing | Bulk | Active | Wirewound | - | 15 µH | ±20% | 30 A | 11A | Shielded | 1.76mOhm Max | - | - | - | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 1.098" L x 1.098" W (27.90mm x 27.90mm) | 0.606" (15.40mm) |
|
CTSFW1335F-2R2MSMD FLAT WIRE POWER INDUCTOR Central Technologies |
5 |
|
Datasheet
|
CTSFW1335F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 2.2 µH | ±20% | 14 A | 18A | Shielded | 6.3mOhm Max | - | - | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.154" (3.90mm) |
|
|
CTSFW1335F-1R2MSMD FLAT WIRE POWER INDUCTOR Central Technologies |
5 |
|
Datasheet
|
CTSFW1335F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 1.2 µH | ±20% | 17 A | 28A | Shielded | 3.1mOhm Max | - | - | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.154" (3.90mm) |
