Fixed Inductors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
26101CFIXED IND 100UH 970MA 350MOHM SM Murata Power Solutions Inc. |
330 |
|
Datasheet
|
2600 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 100 µH | - | 970 mA | - | Unshielded | 350mOhm Max | - | 6.56MHz | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.394" L x 0.354" W (10.00mm x 9.00mm) | 0.228" (5.80mm) |
|
12RS473CFIXED IND 47UH 2.2A 100 MOHM TH Murata Power Solutions Inc. |
144 |
|
Datasheet
|
1200RS | Radial, Vertical Cylinder, 4 Leads | Bulk | Active | Wirewound | - | 47 µH | ±15% | 2.2 A | - | Shielded | 100mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Through Hole | - | 0.413" Dia (10.50mm) | 0.335" (8.50mm) |
|
38L432CFIXED IND 4.3UH 6.8A 9.7MOHM SMD Murata Power Solutions Inc. |
628 |
|
Datasheet
|
3800 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 4.3 µH | ±20% | 6.8 A | 8.8A | Unshielded | 9.7mOhm Max | - | - | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
17476CFIXED IND 47MH 30MA 154 OHM TH Murata Power Solutions Inc. |
38 |
|
Datasheet
|
1700 | Radial, Vertical Cylinder | Tray | Active | Wirewound | - | 47 mH | ±10% | 30 mA | - | Unshielded | 154Ohm Max | 90 @ 50kHz | 250kHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | Radial Lead | 0.283" Dia (7.20mm) | 0.413" (10.50mm) |
|
18R106CFIXED IND 10MH 130MA 12 OHM TH Murata Power Solutions Inc. |
59 |
|
Datasheet
|
1800R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 10 mH | ±10% | 130 mA | - | Unshielded | 12Ohm Max | 142 @ 40kHz | 580kHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | Radial Lead | 0.539" Dia (13.70mm) | 0.626" (15.90mm) |
|
|
18R475CFIXED IND 4.7MH 200MA 4.6 OHM TH Murata Power Solutions Inc. |
32 |
|
Datasheet
|
1800R | Radial, Vertical Cylinder | Bulk | Active | Wirewound | - | 4.7 mH | ±10% | 200 mA | - | Unshielded | 4.6Ohm Max | 126 @ 40kHz | 870kHz | - | 0°C ~ 70°C | 1 kHz | - | Through Hole | Radial Lead | 0.539" Dia (13.70mm) | 0.626" (15.90mm) |
|
19R153CFIXED IND 15UH 4.8A 22 MOHM TH Murata Power Solutions Inc. |
73 |
|
Datasheet
|
1900R | Radial, Vertical Cylinder | Box | Active | Wirewound | - | 15 µH | ±10% | 4.8 A | - | Unshielded | 22mOhm Max | - | - | - | -40°C ~ 95°C | 1 kHz | - | Through Hole | Radial Lead | 0.472" Dia (12.00mm) | 0.827" (21.00mm) |
|
33470CFIXED IND 47UH 3.5A 48 MOHM TH Murata Power Solutions Inc. |
63 |
|
Datasheet
|
3300 | Radial, Vertical, 4 Leads (Open) | Tray | Active | Toroidal | - | 47 µH | ±15% | 3.5 A | - | Unshielded | 48mOhm Max | 3.4 @ 1MHz | 17MHz | - | -40°C ~ 125°C | 1 MHz | - | Through Hole | - | 1.142" L x 0.642" W (29.00mm x 16.30mm) | 1.220" (31.00mm) |
|
234R7CFIXED IND 4.7UH 1.48A 68MOHM SMD Murata Power Solutions Inc. |
691 |
|
Datasheet
|
2300 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 4.7 µH | - | 1.48 A | - | Unshielded | 68mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.126" (3.20mm) |
|
45683CFIXED IND 68UH 820MA 510MOHM SMD Murata Power Solutions Inc. |
1,595 |
|
Datasheet
|
4500 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 68 µH | ±20% | 820 mA | - | Shielded | 510mOhm Max | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.140" (3.55mm) |
