Single, Pre-Biased Bipolar Transistors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Transistor Type | Current - Collector (Ic) (Max) | Voltage - Collector Emitter Breakdown (Max) | Resistor - Base (R1) | Resistor - Emitter Base (R2) | DC Current Gain (hFE) (Min) @ Ic, Vce | Vce Saturation (Max) @ Ib, Ic | Current - Collector Cutoff (Max) | Frequency - Transition | Power - Max | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
,TO-226_straightlead.jpg)
|
PDTC143ZS,126TRANS PREBIAS NPN 50V TO92-3 NXP USA Inc. |
4,822 |
|
Datasheet
|
- | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | Tape & Box (TB) | Obsolete | NPN - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | 47 kOhms | 100 @ 10mA, 5V | 100mV @ 250µA, 5mA | 1µA | - | 500 mW | - | - | Through Hole | TO-92-3 |
|
PDTC144VK,115TRANS PREBIAS NPN 50V 0.1A SMT3 NXP USA Inc. |
5,038 |
|
Datasheet
|
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | NPN - Pre-Biased | 100 mA | 50 V | 47 kOhms | 10 kOhms | 40 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 250 mW | - | - | Surface Mount | SMT3; MPAK |
|
|
PDTC144VS,126TRANS PREBIAS NPN 50V TO92-3 NXP USA Inc. |
8,726 |
|
Datasheet
|
- | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | Tape & Box (TB) | Obsolete | NPN - Pre-Biased | 100 mA | 50 V | 47 kOhms | 10 kOhms | 40 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 500 mW | - | - | Through Hole | TO-92-3 |
|
PDTA114EEAFTRANS PREBIAS PNP 50V 0.1A SC75 NXP USA Inc. |
7,951 |
|
Datasheet
|
- | SC-75, SOT-416 | Tape & Reel (TR) | Obsolete | PNP - Pre-Biased | 100 mA | 50 V | 10 kOhms | 10 kOhms | 30 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | 180 MHz | 150 mW | - | - | Surface Mount | SC-75 |
|
|
PDTC123JU/ZLXTRANS PREBIAS NPN SC70 NXP USA Inc. |
2,081 |
|
Datasheet
|
* | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
PDTC114EU/DG/B3115TRANS PREBIAS NXP USA Inc. |
5,721 |
|
Datasheet
|
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
PDTC143XQA147TRANS PREBIAS NXP USA Inc. |
2,868 |
|
Datasheet
|
PDTC143XQA | 3-XDFN Exposed Pad | Bulk | Active | NPN - Pre-Biased | 100 mA | 50 V | 4.7 kOhms | 10 kOhms | 50 @ 10mA, 5V | 100mV @ 500µA, 10mA | 1µA | 230 MHz | 280 mW | Automotive | AEC-Q101 | Surface Mount | DFN1010D-3 |
|
PDTD114EU135TRANS PREBIAS NXP USA Inc. |
3,181 |
|
Datasheet
|
PDTD1xxxU | SC-70, SOT-323 | Bulk | Active | NPN - Pre-Biased | 500 mA | 50 V | 10 kOhms | 10 kOhms | 70 @ 50mA, 5V | 100mV @ 2.5mA, 50mA | 500nA | 225 MHz | 300 mW | Automotive | AEC-Q101 | Surface Mount | SOT-323 |
|
|
PDTC124XE/DG/B2115TRANS PREBIAS NXP USA Inc. |
5,302 |
|
Datasheet
|
PDTC124X | SC-75, SOT-416 | Bulk | Active | NPN - Pre-Biased | 100 mA | 50 V | 22 kOhms | 47 kOhms | 80 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | - | 150 mW | Automotive | AEC-Q101 | Surface Mount | SC-75 |
|
PDTC114ET215TRANS PREBIAS NPN 50V SOT23-3 NXP Semiconductors |
8,645 |
|
Datasheet
|
- | TO-236-3, SC-59, SOT-23-3 | Bulk | Active | NPN - Pre-Biased | 100 mA | 50 V | 10 kOhms | 10 kOhms | 30 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | 230 MHz | 250 mW | - | - | Surface Mount | SOT23-3 (TO-236) |
